弹丸对混凝土靶体侵彻深度的灰色模拟与预测

陈星明; 刘彤; 肖正学

doi:10.11858/gywlxb.2014.02.014

弹丸对混凝土靶体侵彻深度的灰色模拟与预测

doi: 10.11858/gywlxb.2014.02.014

陈星明^{1, 2,},
刘彤^{1, 2},
肖正学¹

1.
西南科技大学环境与资源学院，四川绵阳 621010
2.
中国工程物理研究院，四川绵阳 621999

基金项目: 国家安全重大基础研究项目(61392020101);西南科技大学国防重点项目(07zx6101)

详细信息

作者简介:
陈星明(1972—), 男, 博士，教授，主要从事工程力学、采矿工程等研究.E-mail:cxm@swust.edu.cn

中图分类号: O24; O385
计量
- 文章访问数: 7330
- HTML全文浏览量: 2429
- PDF下载量: 400
出版历程
- 收稿日期: 2012-06-20
- 修回日期: 2012-09-26

Gray Simulation and Prediction on Projectile Penetration Depth of Concrete Targets

CHEN Xing-Ming^{1, 2
,},
LIU Tong^{1, 2},
XIAO Zheng-Xue¹

1.
Southwest University of Science and Technology, Mianyang 621010, China
2.
China Academy of Engineering Physics, Mianyang 621999, China

摘要

摘要: 由于弹丸对混凝土靶体侵彻机理的未知性及混凝土力学性能的复杂性，因此可将弹丸侵彻混凝土过程看作是一个灰色过程。介绍了弹丸侵彻混凝土靶体侵彻深度的灰色模拟与预测模型GM(1, n)的建立方法和过程，通过GM(1, n)模型可以实现对弹丸侵彻混凝土介质侵彻深度的模拟与预测。通过算例计算表明，此模型对模拟和预测弹丸侵彻混凝土的侵彻深度可行，且计算量较小。
- 侵彻 /
- 深度 /
- 灰色 /
- 模拟 /
- 预测
Abstract: As the unknown nature of mechanism of projectile penetrating the concrete target and the complexity of the mechanical properties of concrete, the projectile penetration concrete can be seen as a gray process.The establishment of methods and processes about the gray simulation and prediction model GM (1, n) were described.Through the gray model GM (1, n), the simulation and prediction of penetration depth of projectile penetrating the concrete target can be achieved.The calculation results show that the model simulation and prediction of projectile penetration depth of concrete penetration is feasible, the result is valid, with a smaller amount of calculation.
- penetration /
- depth /
- gray /
- simulation /
- prediction

HTML全文

图 1 侵彻深度的实验值与模拟值及预测值的比较

Figure 1. The change of target penetration situation with EFP incidence angle

下载: 全尺寸图片幻灯片

表 1 模拟和预测模型的原始数据^[10]

Table 1. Model raw data of simulation and prediction^[10]

No.	σ_t/(MPa)	v_p/(m/s)	P/(m)
1	45	510	0.597
2	23	510	0.834
3	45	612	0.716
4	23	612	1.001
5	45	680	0.795
6	23	680	1.113
7	45	748	0.875
8	23	748	1.224
9	45	850	0.994
10	23	850	1.391
11	45	918	1.074
12	23	918	1.502
13	45	1 020	1.193
14	23	1 020	1.669

下载: 导出CSV

表 2 GM(1，3)模型模拟结果

Table 2. Simulation results of GM(1, 3)

No.	σ_t/(MPa)	v_p/(m/s)	P/(m)	P_sim/(m)	Relative error/(%)
1	45	510	0.597	0.597	0.00
2	23	510	0.834	0.742	11.03
3	45	612	0.716	0.816	-13.97
4	23	612	1.001	1.089	-8.79
5	45	680	0.795	0.791	0.50
6	23	680	1.113	1.129	-1.44
7	45	748	0.875	0.856	2.17

下载: 导出CSV

表 3 GM(1，3)模型预测结果

Table 3. Simulation Result of GM(1, 3)

No.	σ_t/(MPa)	v/(m/s)	P/(m)	P_pre/(m)	Relative error/(%)
8	23	748	1.224	1.204	1.63
9	45	850	0.994	0.971	2.31
10	23	850	1.391	1.320	5.10
11	45	918	1.074	1.049	2.33
12	23	918	1.502	1.398	6.92
13	45	1 020	1.193	1.166	2.26
14	23	1 020	1.669	1.514	9.29

下载: 导出CSV
