缺陷对圆管膨胀断裂影响的实验研究

金山; 张世文; 龙建华

doi:10.11858/gywlxb.2011.02.017

缺陷对圆管膨胀断裂影响的实验研究

doi: 10.11858/gywlxb.2011.02.017

中国工程物理研究院流体物理研究所，冲击波物理与爆轰物理国防科技重点实验室，四川绵阳 621900

详细信息

通讯作者:
张世文

计量
- 文章访问数: 7602
- HTML全文浏览量: 365
- PDF下载量: 579
出版历程
- 收稿日期: 2009-12-08
- 修回日期: 2010-05-06
- 刊出日期: 2011-04-15

Experimental Study on the Influences of Defects on Expanding Fracture of a Metal Cylinder

National Key Laboratory of Shock Wave and Detonation Physics, Institute of Fluid Physics, CAEP, Mianyang 621900, China

More Information

Corresponding author: ZHANG Shi-Wen

摘要

摘要: 采用高速分幅摄影技术，通过对比实验，获得了清晰的无缺陷和预制缺陷金属圆管膨胀断裂的演化图像。实验结果表明，缺陷大大加速了圆管的断裂过程；有缺陷圆管的产物开始泄漏的时间比无缺陷圆管提前5.5 s，采用应力/应变集中法很好地解释了这种现象。另外，针对预制缺陷圆管膨胀断裂时出现的裂块较小而数量较多、无缺陷圆管膨胀断裂时裂块相对较大而数量较少的现象，采用Mott波理论进行了合理的解释。
- 爆炸力学 /
- 圆管 /
- 缺陷 /
- 膨胀断裂 /
- Mott波
Abstract: By means of high-speed frame photography, clear images of the expanding fracture of two metal cylinders with and without a notch were obtained. The experimental results showed that the notch defect would significantly accelerate the fracture process of the cylinder. For the metal cylinder containing a prefabricated notch, the leakage time of detonation products (5.5 s) is earlier than that without a notch, which can be satisfactorily explained by stress or strain concentration. Furthermore, using Mott wave theory, it is well explained that the fragments of the metal cylinder with a notch defect are smaller and more abundant than that without defect.
- mechanics of explosion /
- cylinder /
- defect /
- expanding fracture /
- Mott wave

HTML全文

参考文献(14)

Mott N F. Fragmentation of H. E. Shells: A Theoretical Formula for the Distribution of Weights of Fragments, AC3642 [R]. UK: Ministry of Supply, 1943.

Mott N F. A Theory of the Fragmentation of Shells and Bombs, AC4035 [R]. UK: Ministry of Supply, 1943.

Mott N F. Fragmentation of Shell Cases [J]. Proc R Soc London Ser A, 1947, 189(1018): 300-308.

Grady D. Investigation of Explosively Driven Fragmentation of Metals-Two-Dimensional Fracture and Fragmentation of Metal Shells, UCRL-CR-152264 [R]. California: Lawrence Livermore National Laboratory, 2003.

Tang T G, Gu Y, Li Q Z, et al. Expanding Fracture of Steel Cylinder Shell by Detonation Driving [J]. Explosion and Shock Waves, 2003, 23(6): 529-533. (in Chinese)

汤铁钢, 谷岩, 李庆忠, 等. 爆轰加载下金属柱壳膨胀破裂过程研究 [J]. 爆炸与冲击, 2003, 23(6): 529-533.

Zhang C Y. Experimental and Simulation Study on the Influences of the Guard Ring on the Metal Cylinder Driven by Two Head-on Colliding Detonation Waves [D] . Mianyang: China Academy of Engineering Physics, 2005. (in Chinese)

张崇玉. 爆轰波对碰驱动下保护环对金属圆管保护的实验和数值模拟研究 [D]. 绵阳: 中国工程物理研究院, 2005.

Zhang S W, Liu C L, Yu J Q. Influences of Microdefects on Expanding Fracture of a Metal Cylinder [J]. Explosion and Shock Waves, 2008, 28(4): 316-323. (in Chinese)

张世文, 刘仓理, 于锦泉. 微缺陷对圆管膨胀断裂的影响 [J]. 爆炸与冲击, 2008, 28(4): 316-323.

Tang T G, Li Q Z, Sun X L, et al. Strain-Rate Effects of Expanding Fracture of 45 Steel Cylinder Shells Driven by Detonation [J]. Explosion and Shock Waves, 2006, 26(2): 129-133. (in Chinese)

汤铁钢, 李庆忠, 孙学林, 等. 45钢柱壳膨胀断裂的应变率效应 [J]. 爆炸与冲击, 2006, 26(2): 129-133.

Zhang S W, Jin S, Liu C L. Simulation of the Dynamic Expanding Process of Thick-Walled Cylinder with Defects [J]. Chinese Journal of Applied Mechanics, 2010, 27(3): 622-625. (in Chinese)

张世文, 金山, 刘仓理. 含缺陷厚壁圆管爆轰膨胀断裂的数值模拟 [J]. 应用力学学报, 2010, 27(3): 622-625.
