水中空气隔层衰减冲击波性能研究

姚熊亮; 杨文山; 初文华; 张阿漫

doi:10.11858/gywlxb.2011.02.013

水中空气隔层衰减冲击波性能研究

doi: 10.11858/gywlxb.2011.02.013

哈尔滨工程大学船舶工程学院，黑龙江哈尔滨 150001

详细信息

通讯作者:
杨文山

计量
- 文章访问数: 8039
- HTML全文浏览量: 420
- PDF下载量: 640
出版历程
- 收稿日期: 2009-10-13
- 修回日期: 2010-07-08
- 刊出日期: 2011-04-15

Research on Performance of the Underwater Air Buffer Weakening Shock Wave

College of Shipbuilding Engineering, Harbin Engineering University, Harbin 150001, China

More Information

Corresponding author: YANG Wen-Shan

摘要

摘要: 根据鱼雷对舰船毁伤的特点，建立了多介质水下爆炸数值模型，提出了交界面处理及广义光滑长度计算方法，编制了多介质水下爆炸计算程序，并对水下爆炸空气隔层衰减冲击波的性能进行了定量分析。结果表明：无论是接触爆炸还是非接触爆炸，空气隔层均可有效衰减冲击波，并且接触爆炸中空气隔层衰减冲击波的效果更好，最大可使冲击压力峰值降低约55%；空气隔层厚度与爆炸厚度之比为1时便可达到较好的衰减冲击波效果，继续增加空气隔层厚度对衰减冲击波效果影响不大。研究结果可为舰船结构防护及防雷舱的结构设计提供参考。
- 水下爆炸 /
- 空气隔层 /
- 衰减冲击波 /
- 光滑粒子流体动力学
Abstract: Based on the characteristics of the damage on the ship caused by the torpedo, the numerical model of multi-medium underwater explosions was established, where the methods of treating interface and calculating generalized smooth length were presented. According to this new model, the programs of multi-medium underwater explosions were worked out, and a quantitative analysis was made on the performance of the underwater air buffer weakening shock wave. The results show that the shock wave can be significantly attenuated by the air buffer, whether in contact explosions or non-contact explosions. And the attenuation effect of the air buffer in contact explosions is better than that in non-contact explosions. The pressure peak of the shock wave can be decreased by nearly 55% by the air buffer in contact explosions. When the ratio between the thickness of the air buffer and explosion equals 1, the effect of the air buffer on weakening shock wave is obvious, and further increasing the thickness of the air buffer has little influence on the attenuation effect. The research results will provide reference for the structure design of the ship protection system and torpedo defense cabin.
- underwater explosions /
- air buffer /
- weakening shock wave /
- smoothed particle hydrodynamics

HTML全文

参考文献(19)

Shipboard of Surface Warship Subjected to Underwater Contact Explosion [J]. Explosion and Shock Waves, 2004, 24(2): 133-139. (in Chinese)

朱锡, 张振华, 刘润泉, 等. 水面舰艇舷侧防雷舱结构模型抗爆试验研究 [J]. 爆炸与冲击, 2004, 24(2): 133-139.

Zhang Z H, Zhu X, Huang Y Y, et al. Theoretical Research on the Defendence of Cabin near Shipboard of Surface Warship Subjected to Underwater Contact Explosion [J]. Journal of Ship Mechanics, 2006, 10(1): 113-119. (in Chinese)

张振华, 朱锡, 黄玉盈, 等. 水面舰艇舷侧防雷舱结构水下抗爆防护机理研究 [J]. 船舶力学, 2006, 10(1): 113-119.

Wang Y, Hua H X, Chen Y, et al. New Concept of Ship Anti-Shock Layer in Underwater Explosion Wave Isolation [J]. Science Technology Review, 2009, 27(3): 21-26. (in Chinese)

汪玉, 华宏星, 谌勇, 等. 舰艇抗冲瓦整体冲击隔离新概念及其机理研究 [J]. 科技导报, 2009, 27(3): 21-26.

Li Y J, Li G H, Zhao B L, et al. Influence of Double Hull Structure on the Effects of Underwater Explosion [J]. Journal of Ship Mechanics, 2006, 10(5): 127-134. (in Chinese)

李玉节, 李国华, 赵本立, 等. 双层壳体对水下爆炸作用的影响研究 [J]. 船舶力学, 2006, 10(5): 127-134.

Yu S Y. Model Test and Numerical Calculation on the Ship Protective Structures Underwater Contact Explosion [D]. Harbin: Harbin Engineering University, 2007: 44-58. (in Chinese)

于诗源. 舰船防护结构的水下接触爆炸模型试验研究及数值计算 [D]. 哈尔滨: 哈尔滨工程大学, 2007: 44-58.

Fan Z J, Shen Z W, Ma H H, et al. Experimental Study on Attenuation of Underwater Shock Wave by Air Interlayer [J]. Journal of University of Science and Technology of China, 2007, 37(10): 1306-1311. (in Chinese)

樊自建, 沈兆武, 马宏昊, 等. 空气隔层对水中冲击波衰减效果的实验研究 [J]. 中国科学技术大学学报, 2007, 37(10): 1306-1311.

Liu G R, Liu M B. Smoothed Particle Hydrodynamics-A Meshfree Particle Method [M]. Translated by Han X, Yang G, Qiang H F. Changsha: Hunan University Press, 2005: 1-432. (in Chinese)

Liu G R, Liu M B. 光滑粒子流体动力学--一种无网格粒子法 [M]. 韩旭, 杨刚, 强洪夫, 译. 长沙: 湖南大学出版社, 2005: 1-432.

Liu M B, Liu G R, Lam K Y. Investigations into Water Mitigation Using a Meshless Particle Method [J]. Shock Waves, 2002, 12(3): 181-195.

Bai J S, Chen S H, Li P, et al. High Resolution Computation of the Under Water Explosion [J]. Chinese Journal of Applied Mechanics, 2003, 20(1): 103-106. (in Chinese)

柏劲松, 陈森华, 李平, 等. 水下爆炸过程的高精度数值计算 [J]. 应用力学学报, 2003, 20(1): 103-106.

Tan H. Introduction to Experimental Shock Wave Physics [M]. Beijing: National Defence Industry Press, 2007: 15-66. (in Chinese)

谭华. 实验冲击波物理导引 [M]. 北京: 国防工业出版社, 2007: 15-66.
